BlackView MP100 AMD R7 5825U16GB512GB1xHDMI+1xDPRJ45BTWiFIW11P Black
Štampaj
Lista želja
1 bod = 1 RSD
Više detalja o bodovima
Web cena:
pouzećem ili kartice jednokratno
Maloprodajna cena:
Ne odgovara Vam cena?
Upišite cenu koja Vam je odgovarajuća. Potrudićemo se da Vam damo najbolju ponudu
Molimo Vas upišite cenu koja je odgovarajuća.
Potrudićemo se da Vam u najskorijem roku damo najbolju ponudu.
Uspešno smo primili Vaš upit.
Kontaktiraćemo Vas u što skorijem vremenskom periodu.
Hvala Vam na poverenju. PočetnaBlackView MP100 AMD R7 5825U/16GB/512GB/1xHDMI+1xDP/RJ45/BT/WiFI/W11P Black | ||
Product Appearance |
|
|
Type | Spec. | Standard Configuration |
Product | Product Type | MINI PC |
| Dimension | 127*127*45mm |
| Case Material | Plastic+Metals |
System Hardware Configuration |
|
|
Type | Spec. | Description |
CPU | Model | AMD Ryzen™ 7 5700U |
| Lithography | TSMC 7nm FinFET |
| Total Cores | 8 Core ,16 Threads |
| Cache | L2 cache 4MB,L3 cache 8MB |
| Speed | 1.8GHz |
| Max. Turbo Speed | 4.3 GHz |
| Power Consumption | 25W |
GPU | Model | AMD Radeon™ Graphics |
| Cores | 8 Core |
| Speed | 1900MHz |
| Max Resolution | Max Resolution (HDMI) 3840x2160@60Hz,Max Resolution (DP) 3840x2160@144Hz,Max Resolution (Type C) 3840x2160@60Hz |
Memory | Model | 2*SODIMM LPDDR4 (Up to 64GB) |
| Speed | 3200MHz |
| Capacity | DDR4 Flush-mount,single channel 16GB / Dual channel 32GB |
Storage | SSD | 512GB&1TB(M.2 2280 PCIE3.0 SSD) |
| Interface type | 1* M.2 2280 NVME +1*NVME/SATA3.0,Up to 2TB |
| 2.5'' SSD | Optional, 2.5 inch 7mm SATA port SSD/HDD, Max 2TB |
RTC | BIOS | Real-time Clock, Time Boot |
Auto Power On | BIOS | Support auto power on after electrified |
Diskless Network | BIOS | Support uefi/Legacy Diskless Switch On |
TPM | CPU integratesTPM | Support TPM 2.0 |
multi-screen display | Video Output | In the system, HDMI1+DP two-screen display and Type-C three-screen display are supported(Any Type-C port, but does not support dual Type-C simultaneous display) |
Heat-dissipating method | Heat-dissipating method | Copper tube + copper fin + fan |
FAN | FAN | 5V~0.5A/2.5W /Rated Speed2250rpm |
LED | State | Button light: blue light running, red light sleeping, atmosphere light: running breathing color RGB (The ambient light is not adjustable and cannot be turned off) |
Internet Connection |
|
|
Type | Spec. | Description |
WIFI | Model | M.2 E_Key |
| Protocol | IEEE 802.11 a, b/g, n, ac,ax |
Bluetooth | Model | M.2 E_Key |
| Protocol | Support Bluetooth 5.2 |
3G | Built-in | No |
4G | Built-in | No |
Ethernet | LAN1 | 10M/100M/1000M Self-adaption |
I/O |
|
|
Type | Spec. | Description |
USB | USB2.0 | USB2.0 Type-A*1 480Mbps |
USB | USB3.0 | USB3.2 Gen2 Type-A*2 10Gbps |
TF | Expansion Memory | No |
HDMI | AV Output | HDMI 2.0b(Max 4K 60HZ)*1 |
DP | AV Output | DP1.4(Max 4K 144HZ)*1 |
VGA | Video Output | No |
RJ45 | Gigabyte Ethernet | RJ45 1000Mbps *1 Self-adaption |
Type C | Data Transmission | Type_C *2(full-featured)10Gbps/Max 4K 60HZ |
POWER | Power Button | x1 |
DC IN | Power Supply Input | 5.5/2.1mm DC Jack x1 |
Audio-in/out | Audio-in/out | 3.5mm Phone Jack x1 (Two-in-one interface) |
Antenna1 | FPC Antenna | WiFi 2.4+5G+BT x1 |
Antenna2 | FPC Antenna | WIFI 6.0 |
SIM | Micro SIM | No Supporting |
Software Configuration |
|
|
Type | Spec. | Description |
OS | Version | Win11 pro |
Environment |
|
|
Type | Spec. | Description |
Environment | Working Temperature | 0~40°C |
| Memory Temperature | -20~60°C |
| Humidity | 90% @ 40 °C (No Condensation) |
BlackView MP100 AMD R7 5825U/16GB/512GB/1xHDMI+1xDP/RJ45/BT/WiFI/W11P Black | ||
Product Appearance |
|
|
Type | Spec. | Standard Configuration |
Product | Product Type | MINI PC |
| Dimension | 127*127*45mm |
| Case Material | Plastic+Metals |
System Hardware Configuration |
|
|
Type | Spec. | Description |
CPU | Model | AMD Ryzen™ 7 5700U |
| Lithography | TSMC 7nm FinFET |
| Total Cores | 8 Core ,16 Threads |
| Cache | L2 cache 4MB,L3 cache 8MB |
| Speed | 1.8GHz |
| Max. Turbo Speed | 4.3 GHz |
| Power Consumption | 25W |
GPU | Model | AMD Radeon™ Graphics |
| Cores | 8 Core |
| Speed | 1900MHz |
| Max Resolution | Max Resolution (HDMI) 3840x2160@60Hz,Max Resolution (DP) 3840x2160@144Hz,Max Resolution (Type C) 3840x2160@60Hz |
Memory | Model | 2*SODIMM LPDDR4 (Up to 64GB) |
| Speed | 3200MHz |
| Capacity | DDR4 Flush-mount,single channel 16GB / Dual channel 32GB |
Storage | SSD | 512GB&1TB(M.2 2280 PCIE3.0 SSD) |
| Interface type | 1* M.2 2280 NVME +1*NVME/SATA3.0,Up to 2TB |
| 2.5'' SSD | Optional, 2.5 inch 7mm SATA port SSD/HDD, Max 2TB |
RTC | BIOS | Real-time Clock, Time Boot |
Auto Power On | BIOS | Support auto power on after electrified |
Diskless Network | BIOS | Support uefi/Legacy Diskless Switch On |
TPM | CPU integratesTPM | Support TPM 2.0 |
multi-screen display | Video Output | In the system, HDMI1+DP two-screen display and Type-C three-screen display are supported(Any Type-C port, but does not support dual Type-C simultaneous display) |
Heat-dissipating method | Heat-dissipating method | Copper tube + copper fin + fan |
FAN | FAN | 5V~0.5A/2.5W /Rated Speed2250rpm |
LED | State | Button light: blue light running, red light sleeping, atmosphere light: running breathing color RGB (The ambient light is not adjustable and cannot be turned off) |
Internet Connection |
|
|
Type | Spec. | Description |
WIFI | Model | M.2 E_Key |
| Protocol | IEEE 802.11 a, b/g, n, ac,ax |
Bluetooth | Model | M.2 E_Key |
| Protocol | Support Bluetooth 5.2 |
3G | Built-in | No |
4G | Built-in | No |
Ethernet | LAN1 | 10M/100M/1000M Self-adaption |
I/O |
|
|
Type | Spec. | Description |
USB | USB2.0 | USB2.0 Type-A*1 480Mbps |
USB | USB3.0 | USB3.2 Gen2 Type-A*2 10Gbps |
TF | Expansion Memory | No |
HDMI | AV Output | HDMI 2.0b(Max 4K 60HZ)*1 |
DP | AV Output | DP1.4(Max 4K 144HZ)*1 |
VGA | Video Output | No |
RJ45 | Gigabyte Ethernet | RJ45 1000Mbps *1 Self-adaption |
Type C | Data Transmission | Type_C *2(full-featured)10Gbps/Max 4K 60HZ |
POWER | Power Button | x1 |
DC IN | Power Supply Input | 5.5/2.1mm DC Jack x1 |
Audio-in/out | Audio-in/out | 3.5mm Phone Jack x1 (Two-in-one interface) |
Antenna1 | FPC Antenna | WiFi 2.4+5G+BT x1 |
Antenna2 | FPC Antenna | WIFI 6.0 |
SIM | Micro SIM | No Supporting |
Software Configuration |
|
|
Type | Spec. | Description |
OS | Version | Win11 pro |
Environment |
|
|
Type | Spec. | Description |
Environment | Working Temperature | 0~40°C |
| Memory Temperature | -20~60°C |
| Humidity | 90% @ 40 °C (No Condensation) |
Naziv: BlackView MP100 AMD R7 5825U16GB512GB1xHDMI+1xDPRJ45BTWiFIW11P Black
Jedinica mere: kom
Uvoznik: Tačan podatak o uvozniku i zemlji porekla je naveden na deklaraciji na proizvodu.
