Intel NUC i3-10110UDDR4M.2 SSDHDMIDPEU CORD NUC10i3FNHN2

Processor

Processor manufacturer

Intel

Processor generation

Intel® Core™ i3 10th Generation

Processor

i3-10110U

Processor frequency

2.1 GHz

Processor number of cores

2

Processor threads

4

Processor lithography

14 nm

Processor boosted frequency

4.1 GHz

Processor cache

4 MB

Design thermal power (TDP)

25 W

Code name of the processor

Comet Lake

Memory

Memory slots type

SO-DIMM

  Number of DIMM slots

2

Number of memory slots

2

Maximum amount of internal memory

64 GB

Memory bandwidth (maximum)

42.6 GB/s

Memory operating voltage

1.2 V

Supported memory clock speeds

2666 MHz

Supported memory types

DDR4-SDRAM

Memory channels

Dual-channel

Removable memory card slot

SDXC with UHS-II support

ECC

Not

Data storage medium

Supported drive types

HDD & SSD

Storage drive sizes supported

M.2,2.5

SSD format

M.2

Number of storage drives supported

2

RAID types

0, 1

Integrated card reader

That

Compatible memory cards

SDXC

Graphics

On-board graphics adapter

Not

Graphics adapter family

Intel

On-board graphics adapter model

Intel® UHD Graphics

Number of displays supported

3

Superior Wi-Fi standard

Wi-Fi 6 (802.11ax)

Wi-Fi standards

Wi-Fi 6 (802.11ax)

WLAN controller model

Intel Wi-Fi 6 AX201

LAN controller

Intel® I219-V

Ports & interfaces

Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports

3

Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports

2

Internal USB 2.0 ports quantity

2

Number of HDMI ports

1

HDMI version

2.0b

DisplayPort version

1.2

Number of Ethernet LAN (RJ-45) ports

1

Number of SATA III connectors

2

USB version

2.0/3.2 Gen 2 (3.1 Gen 2)

Number of USB ports

7

Graphic output

HDMI 2.0b; USB-C (DP1.2)

Number of Thunderbolt 3 ports

1

M.2 card slot (storage)

2242/2280

Expansion slots

PCI Express slots version

3.0

Number of M.2 (M) slots

1

PCI Express sonfigurations

1x4, 2x2, 1x2+2x1, 4x1

Design

Case type

UCFF

Product color

Black

Product type

Mini PC Barebones

Effect

Dimensions of the motherboard

UCFF

Processor slot

BGA 1528

Trusted Platform Module (TPM)

Not

Audio output channels

7.1 channels

Supported RAID configurations

2.5" HDD/SSD + M.2 SATA SSD (RAID-0 RAID-1)

Installed operating system

Not

Spending management

Power supply type

External AC adapter

AC adapter output voltage

19 V

Weight and dimensions

Width

117 mm

Depth

112 mm

Height

51 mm
