Matična ploča AM4 MSI X570 GAMING EDGE WIFI
Štampaj
Lista želja
Broj bodova koje osvajate kupovinom ovog artikla
250
1 bod = 1 RSD
Više detalja o bodovima
Web cena:
*Cena za gotovinu,
pouzećem ili kartice jednokratno
24.830,00 rsd.
Maloprodajna cena:
*Za odloženo plaćanje
27.129,00 rsd.
Ne odgovara Vam cena?
Upišite cenu koja Vam je odgovarajuća. Potrudićemo se da Vam damo najbolju ponudu
Molimo Vas upišite cenu koja je odgovarajuća.
Potrudićemo se da Vam u najskorijem roku damo najbolju ponudu.
Uspešno smo primili Vaš upit.
Kontaktiraćemo Vas u što skorijem vremenskom periodu.
Hvala Vam na poverenju. Početna- Tip procesora
- AMD
- Podnožje
- AMD® AM4
- Čipset
- AMD® X570
- Format ploče
- ATX
- Podržani procesori
- 2nd and 3rd Gen AMD Ryzen Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics Desktop Processors for Socket AM4
- Podržana memorija
- DDR4
- Memorija
- - 4x DDR4 memory slots, support up to 128GB - s3rd Gen AMD Ryzen™ Processors support DDR4 1866 2133 2400 2667 2800 2933 3000 3066 3200 Mhz by JEDEC, and 2667 2800 2933 3000 3066 3200 3466 3600 3733 3866 4000 4133 4266 4400 Mhz by A-XMP OC MODE - 2nd Gen AMD Ryzen™ Processors, 1st and 2nd Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors support DDR4 1866 2133 2400 2667 2800 2933 3000 3066 3200 Mhz by JEDEC, and 2667 2800 2933 3000 3066 3200 3466 Mhz by A-XMP OC MODE - Dual channel memory architecture - Supports non-ECC UDIMM memory - Supports ECC UDIMM memory (non-ECC mode) - Supports un-buffered memory
- Multi-GPU podrška
- Supports 2-Way AMD CrossFire Technology
- Integrisana grafička karta
- - 1x HDMI 1.4 port, supports a maximum resolution of 4096x2160 @24Hz
- Slotovi za proširenje
- - 1x PCIe 4.0 3.0 x16 slot (PCI_E1) - 3rd Gen AMD Ryzen™ support PCIe 4.0 x16 mode - 2nd Gen AMD Ryzen™ support PCIe 3.0 x16 mode - Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics support PCIe 3.0 x8 mode - 1x PCIe 4.0 3.0 x16 slot (PCI_E3, supports x4 mode) - 3x PCIe 3.0 x1 slots
- Storage
- AMD® X570 Chipset - 4x SATA 6Gbs ports(SATA3-SATA6) - 2x M.2 slots (Key M) - M2_1 slot (from AMD® Processor) - Supports PCIe 4.0 x4 (3rd Gen AMD Ryzen™) - Supports PCIe 3.0 x4 (2nd Gen AMD Ryzen™ Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics) - Supports 2242 2260 2280 22110 storage devices - M2_2 slot (from AMD® X570 Chipset) - Supports PCIe 3.0 x4 and SATA 6Gbs - Supports 2242 2260 2280 storage devices ASMedia ASM1061 - 2x SATA 6Gbs ports (SATA1, SATA2)
- Mrežna karta
- - 1x Realtek® 8111H Gigabit LAN Controller Intel® Dual Band Wireless-AC 3168 - Supports 802.11 abgnac, dual band (2.4GHz, 5GHz) up to 433 Mbps - Supports Dual Mode Bluetooth® 2.1, 2.1+EDR, 3.0, 4.0, BLE, 4.2 - The Wireless module is pre-install in the M2_3 (Key-E) slot
- Zvučna karta
- Realtek® ALC1220 Codec - 7.1-Channel High Definition Audio - Supports Optical SPDIF output
- USB
- AMD® X570 Chipset - 2x USB 3.2 Gen 2 (SuperSpeed USB 10Gbps) Type-A ports on the back panel - 4x USB 3.2 Gen 1 (SuperSpeed USB) ports through the internal USB 3.2 Gen1 connector - 6x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 2.0 connectors) AMD® Processor - 2x USB 3.2 Gen2 (3rd Gen AMD Ryzen™) or USB 3.2 Gen1 (2nd Gen AMD Ryzen™ Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics) ports (1x Type-A & 1x Type-C) on the back panel - 2x USB 3.2 Gen1 (SuperSpeed USB) Type-A ports on the back panel
- Konektori na zadnjoj strani
- - Keyboard Mouse - Wireless Bluetooth - USB 3.2 Gen1 Type-A - LAN - Audio Connectors - Flash BIOS Button - USB 2.0 - HDMI - USB 3.2 Gen2 Type-A + C - USB 3.2 Gen2 Type-A - Optical SPDIF out
- Interni konektori
- - 1x 24-pin ATX main power connector - 1x 8-pin ATX 12V power connector - 1x 4-pin ATX 12V power connector - 6x SATA 6Gbs connectors - 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) - 2x USB 3.2 Gen1 connectors (supports additional 4 USB 3.2 Gen1 ports) - 1x 4-pin CPU fan connector - 1x 4-pin water-pump connector - 4x 4-pin system fan connectors1x Front panel audio connector - 2x System panel connectors - 1x TPM module connector - 1x Serial port connector - 1x Clear CMOS jumper - 1x Chassis Intrusion connector - 2x 4-pin RGB LED connectors - 2x 3-pin RAINBOW LED connectors - 4x EZ Debug LEDs
- Razno
- {"url":"https:\\www.msi.com\Motherboard\MPG-X570-GAMING-EDGE-WIFI","title":"Link proizvo\u0111a\u010da","target":"_blank"}
- Socket
- AM4
- CPU
- AMD Athlon, AMD Ryzen 3, AMD Ryzen 5, AMD Ryzen 7
- BUS [MHz]
- 1600
- Memorija
- DDR4
- Broj slotova
- 4
- Max. memorije [GB]
- 128
- Takt memorije [MHz]
- 2133, 2400, 2666, 2933, 3000, 3100, 3200, 1866
- AGP 4x8x
- na
- PCI
- na
- PCIe 3.0 x16
- 2
- PCIe x16
- na
- PCIe x8
- na
- PCIe x4
- na
- PCIe x1
- 3
- PCI-X
- na
- PATA
- na
- SATA
- na
- SATA 6Gbs
- 6
- RAID polje
- 0, 1
- Audio
- 6-kanalni audio
- Mreža
- 1x 101001000 Ethernet
- Parallel
- na
- Serial
- na
- PS2 mouse
- 1
- PS2 keyboard
- 1
- eSATA
- 0
- D-sub
- na
- DVI
- na
- Display port
- na
- HDMI
- 1
- RJ45
- 1
- USB 2.0
- 2
- USB 3.0
- 0
- SPDIF Out
- na
- FireWire
- 0
- 4-pin ATX 12V Power
- na
- 8-pin ATX 12V Power
- na
- 20-pin ATX Power
- na
- 24-pin ATX Power
- na
- Front panel audio
- na
- Chasis Intrusion
- na
- CD Audio In
- na
- Chasis Fan Power
- na
- CPU Fan Power
- na
- Format ploče
- ATX
- WLAN connector
- na
- Podrška za integrisani grafičk
- N
- SATA Express
- na
- M.2
- 2
- U.2
- na
- USB 3.1
- 5
- USB 3.1
- 5
- USB 3.2
- 0
Naziv: Matična ploča AM4 MSI X570 GAMING EDGE WIFI
Jedinica mere: kom
Uvoznik: Tačan podatak o uvozniku i zemlji porekla je naveden na deklaraciji na proizvodu.
