Tenda B6 5GHz, 300Mbps, AP/Station/WISP/P2MP/WDS Repeater/Router

Name: Tenda B6 5GHz, 300Mbps, AP/Station/WISP/P2MP/WDS Repeater/Router - G Store & Repair doo
Brand: TENDA
SKU: -1
Price: 8611.81 RSD
Availability: OutOfStock
Rating: 88 (20 reviews)

https://www.gstore.rs/images/products/big/95431.jpg

https://www.gstore.rs/images/products/big/95428.jpg

https://www.gstore.rs/images/products/big/95429.jpg

Štampaj

Lista želja

Šifra: 37163

EAN:

Nema na stanju

Obavesti me kada bude dostupno.

Broj bodova koje osvajate kupovinom ovog artikla 90

1 bod = 1 RSD

Više detalja o bodovima

Raiffeisen Bank

Web kredit na 23 mesečne rate

23 x 413,00 rsd.

Vidi više

Web cena:

*Cena za gotovinu,

pouzećem ili kartice jednokratno

8.612,00 rsd.

Maloprodajna cena:

*Za odloženo plaćanje

9.395,00 rsd.

Ne odgovara Vam cena?

Upišite cenu koja Vam je odgovarajuća. Potrudićemo se da Vam damo najbolju ponudu

B6 5GHz 11n 300Mbps Basestation is designed for PtP and PtMP solutions for rural wireless connectivity and CCTV surveillance.Features with two RP- SMA enable it to pair with dish antenna or sector antenna to establish PtP backhaul connection and P2MP link. It adopts Tenda TDMA (Time Division Multiple Access) proprietary protocol--TD-MAX to improve performance and capacity. The auto-bridging technology enable it easy to setup for both business and home users.

Dimension 194.7*83*42.1mm
Deployment Pole Mount
Application Scenarios PtP, PtMP for rural wireless connectivity and CCTV surveillance
Frequency Range 5GHz
Standard&Protocol IEEE 802.11a/n
Private TDMA Protocol TD-MAX
Maximum wireless speed 300Mbps
Interface 1*10/100Mbps Ethernet Port
Antenna 2*RP-SMA
Reset Button1
GND1
Power Consumption 8.5W
Waterproof Level IP65
LED indicator PoE/LAN,LED1,LED2,LED3
Power Method 24V0.5A Passive PoE
Lightning Protection 6000V
Passive PoE power supply Passive power over ethenet via PoE/LAN ( 4,5pins
-7,8pins)
Voltage range: 21-25V DC
Reception SensitivityMCS0: -96dbm
MCS7: -72dbm
Operating Mode: AP/Station/WISP/P2MP/WDS Repeater/Router
Enable/Disable Wireless RadioSupport
SSID HiddenSupport
SSID IsolationSupport
Channel10/20/30/40MHz
Client Limitation For SSID Support
Wireless Access Control Support
Weak Signal Client Limitation Support
Transmit PowerAdjustable power by 1dBm
WMM Capable Support
APSD Capable Support
Wireless Security 64/128 WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2
Transparent Bridge Support
VLAN Tagging for SSID Support
DHCP Server Support
VPN Pass-through PPTP,L2TP
Schedule Reboot Support
Page Timeout Support
Ping Watchdog Support
Dynamic DNSnoip, dyndns.org
Network Diagnoses Ping, Traceroute, Signal Scan
Time&Date Setting Support
Firmware Upgrade Support
Backup/Restore Configuration Support
Username Managerment Support
SyslogSupport
Managed By Controller PC Software -- CPE Assistant
Package Content 1*5GHz 11N 300Mbps Basestation
1*PoE Power Adapter
1*Quick Installation Guide
Operating Temperature:-30? ~ 60?
Storage Temperature:-40? ~ 70?
Humidity Operating Humidity: 10%~90% non-condensing
Storage Humidity: 10%~90% non-condensing
Default Settings Default login IP:192.168.2.1
Default Login Username:admin
Default Login Password:admin
CertificationFCC/CE/RoHS
