Tenda TEF1109TP-8-102W LAN 8-Port 10/100 Base-TX(Data/Power) +1Base-TX(Data) Ethernet ports Switch
Štampaj
Lista želja
Broj bodova koje osvajate kupovinom ovog artikla
100
1 bod = 1 RSD
Više detalja o bodovima
Web cena:
*Cena za gotovinu,
pouzećem ili kartice jednokratno
9.494,00 rsd.
Maloprodajna cena:
*Za odloženo plaćanje
10.342,00 rsd.
Ne odgovara Vam cena?
Upišite cenu koja Vam je odgovarajuća. Potrudićemo se da Vam damo najbolju ponudu
Molimo Vas upišite cenu koja je odgovarajuća.
Potrudićemo se da Vam u najskorijem roku damo najbolju ponudu.
Uspešno smo primili Vaš upit.
Kontaktiraćemo Vas u što skorijem vremenskom periodu.
Hvala Vam na poverenju. PočetnaThe Gigabit Uplink Port To Guarantee the Transmission Smooth and Stable
It provides 8 10/100M RJ45 ports and 1 gigabit port. By using CAT5e twisted pairs, it can provide power and data transmission to APs, IP cameras, IP phones, and so on, fully loaded
Transmission Distance up to 250m
With the extension technology,data can be transmitted through 250 meters cable which would be a cost-effective replacement for extenders and optical fibers.
Excellent Lightning Protection
The switch supports 6 kV lightning protection for uplink port, protecting the switch from thunderstorms and making it more stable.
What's Special for TEF1109TP-8-102W :
Simple Port VLAN Setup
With VLAN Mode on , ports 1 to 8 are isolated from each other, enabling the switch to isolate broadcast storm, improving LAN security and data transmission.
Network standards IEEE 802.3? IEEE 802.3u?IEEE 802.3x?IEEE 802.3af?IEEE 802.3at
LED indicators:
9* Link/Ack LED indicators
1 * Power LED indicator
Interfaces:
8*10/100 Base-TX Ethernet ports (Data/Power)
1*10/100 Base-TX Ethernet ports (Data)
Transmission media
Recommended: CAT5/5e UTP or better
Fan quantity N/A
Dimensions(L*W*H) 177.5mmx104.0mmx26.0mm
Level of protection:
Lightning protection for ports: 6KV
Lightning protection for power: 6KV
ESD:
Air discharge: ±10kV
Contact discharge: ±8kV
Forwarding mode
Store-and-forward
Switch capacity 2.6 Gbps
Packet forwarding rate 1.34Mpps
Buffer 1.25Mb
MAC address table 2K
Jombo frame N/A
PoE budget
Single port: AF: 15.4W, AT: 30W
Whole device: 92W
Power consumption /
Input voltage
100-240V AC 50/60Hz
51V /2A DC(Power Adapter )
Mounting
Desktop mounting: support
Wall mounting: support
Rack mounting : non-support
Environment
Operating Temperature: 0?~45?
Storage Temperature: -40?~70?
Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
Certificates
FCC?CE?RoHS
Software
Function
Default Mode: If Default mode is enabled, the device works as a general switch and all ports support 10/100Mbps auto-negotiation.
VLAN Mode: If VLAN mode is enabled, VLAN isolation is enabled. Port 1-8 will be isolated respectively (10/100Mbps auto-negotiation), but can communicate with the Uplink port. And the delivery distance of powering and network data is up to 250m (10Mbps).
It provides 8 10/100M RJ45 ports and 1 gigabit port. By using CAT5e twisted pairs, it can provide power and data transmission to APs, IP cameras, IP phones, and so on, fully loaded
Transmission Distance up to 250m
With the extension technology,data can be transmitted through 250 meters cable which would be a cost-effective replacement for extenders and optical fibers.
Excellent Lightning Protection
The switch supports 6 kV lightning protection for uplink port, protecting the switch from thunderstorms and making it more stable.
What's Special for TEF1109TP-8-102W :
Simple Port VLAN Setup
With VLAN Mode on , ports 1 to 8 are isolated from each other, enabling the switch to isolate broadcast storm, improving LAN security and data transmission.
Network standards IEEE 802.3? IEEE 802.3u?IEEE 802.3x?IEEE 802.3af?IEEE 802.3at
LED indicators:
9* Link/Ack LED indicators
1 * Power LED indicator
Interfaces:
8*10/100 Base-TX Ethernet ports (Data/Power)
1*10/100 Base-TX Ethernet ports (Data)
Transmission media
Recommended: CAT5/5e UTP or better
Fan quantity N/A
Dimensions(L*W*H) 177.5mmx104.0mmx26.0mm
Level of protection:
Lightning protection for ports: 6KV
Lightning protection for power: 6KV
ESD:
Air discharge: ±10kV
Contact discharge: ±8kV
Forwarding mode
Store-and-forward
Switch capacity 2.6 Gbps
Packet forwarding rate 1.34Mpps
Buffer 1.25Mb
MAC address table 2K
Jombo frame N/A
PoE budget
Single port: AF: 15.4W, AT: 30W
Whole device: 92W
Power consumption /
Input voltage
100-240V AC 50/60Hz
51V /2A DC(Power Adapter )
Mounting
Desktop mounting: support
Wall mounting: support
Rack mounting : non-support
Environment
Operating Temperature: 0?~45?
Storage Temperature: -40?~70?
Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
Certificates
FCC?CE?RoHS
Software
Function
Default Mode: If Default mode is enabled, the device works as a general switch and all ports support 10/100Mbps auto-negotiation.
VLAN Mode: If VLAN mode is enabled, VLAN isolation is enabled. Port 1-8 will be isolated respectively (10/100Mbps auto-negotiation), but can communicate with the Uplink port. And the delivery distance of powering and network data is up to 250m (10Mbps).
-
The Gigabit Uplink Port To Guarantee the Transmission Smooth and Stable
It provides 8 10/100M RJ45 ports and 1 gigabit port. By using CAT5e twisted pairs, it can provide power and data transmission to APs, IP cameras, IP phones, and so on, fully loaded
Transmission Distance up to 250m
With the extension technology,data can be transmitted through 250 meters cable which would be a cost-effective replacement for extenders and optical fibers.
Excellent Lightning Protection
The switch supports 6 kV lightning protection for uplink port, protecting the switch from thunderstorms and making it more stable.
What's Special for TEF1109TP-8-102W :
Simple Port VLAN Setup
With VLAN Mode on , ports 1 to 8 are isolated from each other, enabling the switch to isolate broadcast storm, improving LAN security and data transmission.
Network standards IEEE 802.3? IEEE 802.3u?IEEE 802.3x?IEEE 802.3af?IEEE 802.3at
LED indicators:
9* Link/Ack LED indicators
1 * Power LED indicator
Interfaces:
8*10/100 Base-TX Ethernet ports (Data/Power)
1*10/100 Base-TX Ethernet ports (Data)
Transmission media
Recommended: CAT5/5e UTP or better
Fan quantity N/A
Dimensions(L*W*H) 177.5mmx104.0mmx26.0mm
Level of protection:
Lightning protection for ports: 6KV
Lightning protection for power: 6KV
ESD:
Air discharge: ±10kV
Contact discharge: ±8kV
Forwarding mode
Store-and-forward
Switch capacity 2.6 Gbps
Packet forwarding rate 1.34Mpps
Buffer 1.25Mb
MAC address table 2K
Jombo frame N/A
PoE budget
Single port: AF: 15.4W, AT: 30W
Whole device: 92W
Power consumption /
Input voltage
100-240V AC 50/60Hz
51V /2A DC(Power Adapter )
Mounting
Desktop mounting: support
Wall mounting: support
Rack mounting : non-support
Environment
Operating Temperature: 0?~45?
Storage Temperature: -40?~70?
Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
Certificates
FCC?CE?RoHS
Software
Function
Default Mode: If Default mode is enabled, the device works as a general switch and all ports support 10/100Mbps auto-negotiation.
VLAN Mode: If VLAN mode is enabled, VLAN isolation is enabled. Port 1-8 will be isolated respectively (10/100Mbps auto-negotiation), but can communicate with the Uplink port. And the delivery distance of powering and network data is up to 250m (10Mbps).
Naziv: Tenda TEF1109TP-8-102W LAN 8-Port 10/100 Base-TX(Data/Power) +1Base-TX(Data) Ethernet ports Switch
Jedinica mere: kom
Uvoznik: Tačan podatak o uvozniku i zemlji porekla je naveden na deklaraciji na proizvodu.
