Tenda TEF1118P-16-150W LAN 16-Port 10/100M + 1 Gigabit SFP Slots Switch

Name: Tenda TEF1118P-16-150W LAN 16-Port 10/100M + 1 Gigabit SFP Slots Switch - G Store & Repair doo
Brand: TENDA
SKU: -1
Price: 18834.18 RSD
Availability: OutOfStock
Rating: 88 (20 reviews)

https://www.gstore.rs/images/products/big/100063.jpg

https://www.gstore.rs/images/products/big/100061.jpg

https://www.gstore.rs/images/products/big/100062.jpg

Štampaj

Lista želja

Šifra: 37103

EAN:

Nema na stanju

Obavesti me kada bude dostupno.

Broj bodova koje osvajate kupovinom ovog artikla 190

1 bod = 1 RSD

Više detalja o bodovima

Raiffeisen Bank

Web kredit na 23 mesečne rate

23 x 902,00 rsd.

Vidi više

Web cena:

*Cena za gotovinu,

pouzećem ili kartice jednokratno

18.834,00 rsd.

Maloprodajna cena:

*Za odloženo plaćanje

20.562,00 rsd.

Ne odgovara Vam cena?

Upišite cenu koja Vam je odgovarajuća. Potrudićemo se da Vam damo najbolju ponudu

TEF1118P-16-150W is a Tenda PoE switch that offers 16 10/100 Mbps Base-TX RJ45 ports, 1 10/100/1000 Mbps Base-T RJ45 ports, and 1 1000 Mbps Base-X SFP port. Ports 1-16 comply with the IEEE 802.3af standard (maximum PoE power output: 15.4 W) and 802.3at standard (maximum PoE power output: 30 W). The switch offers a maximum PoE power output of 135 W and can supply power to and exchange data with APs, IP cameras, and IP phones through CAT5 cables. It also provides simple management modes such as CCTV, VLAN, and Extend to help reduce cabling costs of IP terminals like APs and IP cameras.

Standard&Protocol IEEE 802.3? IEEE 802.3u?IEEE 802.3x?IEEE 802.3af
MTBF=100,000hours
Indicator 16*Link/Act per device
1*G1 Link/Act per device
1*SFP Link/Act per device
1*PoE-MAX per device
1*Power per device
Interface 16 10/100Base-TX ports(Data/Power)
1 10/100/1000Base-T port(Data)
1 1000Base-X SFP port
Lightning Protection 6KV
Store & Forward Yes
exchange capacity 7.2 Gbit/s
Packet Forwarding Rate5.36Mpps
MAC Address Table 4K
PoE supply management Port 1 to Port 16 support IEEE802.3at/af POE standard
PN pass-through 1 2 4 5 +,3 6 7 8 -
Input PowerAC:100-240V~ 50/60Hz
Dimension 294*178*44mm( W x D x H )
Power Consumptionin full configuration:<150W
PoE Max Power Supply:135W
Ports featureCCTV: 1-8 ports based CoS, If multiple IP cameras are connected to the switch, you are recommended to enable this mode and connect the G1 or SFP1 port of this switch to the upstream device to which the monitoring computer connects. This ensures smoother monitoring video playback.
Standard: the switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other.
VLAN: In this mode,1-16 ports of the switch cannot communicate with each other, but can communicate with the G1 and SFP1 ports.Solid DIP switch to isolate ports to prevent broadcast storm and defend DHCP spoofing.
Extend: In this mode, the data rate of 1-8 port of the switch is limited to 10 Mbps, whereas the maximum transmission distance of the port is increased to 250 meters. All the ports of the switch can communicate with each other.
Environment Operating Temperature: 0?~40? (32?~104?)
Storage Temperature: -40?~70? (-40?~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
